CCD 카메라

CB500MG-CM

제이엠제이 XIMEA 0 1,680 2017.04.13 23:02

WILL BE AVAILABLE SOON

50 Megapixels Monochrome CMOS camera with CMOSIS CMV50000

PCIe speed of 20 Gbit/s allows 22 Fps at 12 bit

8K, compact, high resolution camera for: Flat panel inspection (FPD), printed circuit board (PCB) examination, solar panel analysis, persistent stadium and border security, wide area surveillance, cinematography, sports and entertainment, 360 panorama, UAV and Autonomous, Unmanned vehicles, aerial or city mapping.

With flat ribbon flex cable (xiX line) ideal for Embedded vision systems.

Specifications:
Resolution	47.5 MP 7920 x 6004
Sensor type	CMOS B/W
Sensor model	CMOSIS CMV50000
Sensor size	35 mm
Sensor active area	36.4 x 27.6 mm
Pixel size	4.6 μm
Bits per pixel	12, 14
Dynamic range	60 dB
Frame rates	26 Fps
Image data interface	PCI Express (PCIe)
Data I/O	2IN/2OUT
Power requirements	9 Watt
Cooling	Heatsink optional
Lens mount	Active EF-mount
Weight	175 grams
Dimensions WxHxD	60 x 60 x 38 mm
Customs tariff code	8525.80 30 (EU) / 8525.80 40 (USA)
ECCN	EAR99

CB200MG-CM

20 Mpix at 33 Fps
CMOSIS CMV20000
41 mm Black and white CMOS
PCI Express camera - 20 Gbit/s

CB120MG-CM

12 Mpix at 133 Fps
CMOSIS CMV12000
28 mm Black and white CMOS
PCI Express camera - 20 Gbit/s
